Wood Stains & Treatments are used on wood for preservation, sound-proofing, and fire resistance. Our colorants are compatible with all stain, coating, and CCA(Chromated Copper Arsenate) preservative formulations to meet building standards and codes such as ASTM E-90, NFPA 703,and UL Design No. V314.  OrcoStain™ wood stain dyes and wood finishing dyes are selected colorants chosen for their brilliance, clarity and ease of use. The WS Line offers minimal “grain raising” characteristics and excellent water and water-miscible co-solvent solubility properties. The SS Line is recommended in solvent-based systems and for tinting of clear solvent based finishes. Our technical staff is available to prepare custom formulations of both water and solvent soluble dyes and pigments.

Quick Links:

Inorganic Pigments (See KEY)    Orco BV™  |  Orco Chrome™  |  Orco Chromox™  |  Orco CPX™  |  Orco IO™  |  Orco Moly™

                                                     Orco Milori™

Organic Pigments                   OrcoPerm™

Dyes                                           OrcoStain™ WS   |  OrcoStain™ SS

Orco™ Inorganic Pigments

Shade

Index Name

Pigment Name

pH

Light Fastness (1-8)

Heat Stability (°F/°C)

Yellow 184

Orco BV™ Yellow

6 .5-8.0

8

390-520 / 199-271

Yellow 34

Orco Chrome™ Yellow EHT

7

470 / 243

Green 17

Orco Chromox™ Green

6-8

8

1800/ 982

Black 28

Orco CPX™ Black A

6.8

8

1500 / 800

Brown 29

Orco CPX™ Black IR

5.3

8

1500 / 800

Black 30

Orco CPX™ Black IR-2

7.6

8

1500 / 800

Black 27

Orco CPX™ Black DBK

8.6

8

2200 / 1200

Green 17

Orco CPX™ Black ED-G

5.2

8

1500 / 800

Brown 29

Orco CPX™ Black ED/IR-B

4.5

8

1500 / 800

Blue 28

Orco CPX™ Blue BB

9.5

8

1500 / 800

Blue 28

Orco CPX™ Blue ED-RB

4.8

8

1500 / 800

Blue 28

Orco CPX™ Blue TB

10.8

8

1500 / 800

Yellow 164

Orco CPX™ Brown IR-DB

5.6

1500 / 800

Brown 33

Orco CPX™ Brown ED-RB

4.8

8

1500 / 800

Green 17

Orco CPX™ Green IR-G

6.0

1500 / 800

Green 50

Orco CPX™ Green ED-RG

5.9

8

1500 / 800

Green 26

Orco CPX™ Green ED-DG

5.7

8

1500 / 800

Green 50

Orco CPX™ Green BG

9.6

8

1500 / 800

Yellow 216

Orco CPX™ Orange C

9.6

8

600 / 320

Yellow 216

Orco CPX™ Orange ED-MO

4.9

8

600 / 320

Violet 14

Orco CPX™ Violet BV

7.8

8

1100 / 600

Yellow 53

Orco CPX™ Yellow BY

9.5

8

1500 / 800

Yellow 227

Orco CPX™ Yellow CHY

5.4

8

600 / 320

Yellow 53

Orco CPX™ Yellow ED-BY

4.5

8

1500 / 800

Yellow 227

Orco CPX™ Yellow ED-CHY

4.3

8

600 / 320

Brown 24

Orco CPX™ Yellow ED-GY

4.2

8

1500 / 800

Yellow 42

Orco IO™ Yellow S

3-7

Yellow 42

Orco IO™ Yellow S-M

3-7

Red 101

Orco IO™ Red S-M

4.5-7.5

930-1382 / 499-750

Black 11

Orco IO™ Black S-M

5-8

Black 26

Orco IO™ Black HT

7

8

1292/700

Blue 27

Orco Milori™ Blue NC

3-5

7-8

350 / 177

Red 104

OrcoMoly™ Orange RG

6-7.5

7-8

390/199

OrcoPerm™ Organic Pigments

Shade

Index Name

OrcoPerm™

OR

pH

Light Fastness (1-8)

Heat Stability (°F/°C)

Yellow 1

Yellow G

6-7

4-6

284 / 140

Yellow 14

Yellow 2GN

5.0-7.5

3-5

390/199

Yellow 74

Fast Yellow 5GX

5.5-7.5

7-8

280 / 138

Yellow 83

Golden Yellow RN

5.5-7.5

7-8

390 / 199

Yellow 93

Yellow G

5.5-8.5

7-8

392-536 / 200-280

Yellow 97

Yellow FGL

6.5-8.5

5-8

350/ 177

Yellow 139

Yellow 2RF

5-7

7-8

390-460 / 199-238

Yellow 151

Yellow H4G

5-7.5

6-8

390-500 / 199-260

Yellow 194

Yellow F2G

5.5-7.5

7-8

390/ 199

Orange 5

Fast Orange RN

4-7.5

5-6

280-320 / 138-160

Orange 16

Fast Orange G

6-7.5

2-5

275-340 / 135-171

Orange 36

Orange HL

9.5

7-8

320-500 / 160-260

Orange 43

Orange GRL

6-7

5-7

390-590 / 190-310

Orange 67

Orange L

5.5-7.5

7

390 / 199

Red 5

Carmine FBX

5-7.5

5-6

1500 / 800

Red 49:1

Red LB

5.5-7.5

2-4

260 / 127

Red 52:2

Maroon CM

5-7.5

3-5

460 / 238

Red 112

Red FGR

5.5-7

6-8

320-570 / 160-299

Red 146

Carmine FBB

5-6.5

4-5D

350-390 / 177-199

Red 149

Fast Red B

6-7.5

6-8

430-560 / 221-293

Red 166

Scarlet R

6-7.5

7-8

390-570 / 199-299

Red 176

Carmine HFC

6-7.5

5-7

350-520 / 177-271

Violet 23

Violet 4BN

5-7

6-8

320-535 / 160-279

Violet 29

Fast Bordeaux

5-6

7-8

390-570 / 199-299

Blue 15:2

Blue AFR

6-8

8

390-500 / 199-260

Blue 60

Blue A3R

6-8

7-8

392 / 200

Green 7

Green BN

5.5-8

8

390-500 / 199-260

Green 7

Green YN

5.5-8

8

350-500 / 177-260

Green 36

Cyanine Green 8G

5.5-8

8

390-500 / 199-260

OrcoStain™ WS Water-Soluble Dyes

Shade

Index Name

OrcoStain™ WS

Chemical Class

Light Fastness (ISO)

Solubility (water-g/L)

Acid Yellow 17

Yellow 2G

MonoAzo

7

60

Acid Yellow 99

Yellow GRN

MonoAzo Metallized

4-5

30

Acid Yellow 127

Yellow 5G

MonoAzo

5

60

Acid Yellow 23

Tartrazine X

MonoAzo

4

60

Acid Yellow 73

Fluoresceine

Xanthene

2

60

Acid Orange 7

Orange A

MonoAzo

4

50

Acid Red 1

Phloxine GR

MonoAzo

5

50

Acid Red 18

Scarlet 3RL

MonoAzo

4

40

Acid Red 73

Scarlet MR

DisAzo

6

50

Acid Red 52

Rhodamine B

Xanthene

3

30

Acid Red 14

Rubine CWH

MonoAzo

3

45

Acid Violet 54

Brilliant Red 10B

MonoAzo

4-5

50

Acid Blue 25

Alizarine Blue SWA

Anthraquinone

5-6

60

Acid Blue 40

Sapphire 2GL

Anthraquinone

6

50

Acid Blue 113

Dark Blue AS

DiAzo

5-7

30

Acid Green 16

Napthalamine Green 2G

Triphenylmethane

3

30

Acid Green 25

Alizarine Green GHN

Anthraquinone

6

40

Acid Black 1

Blue Black B

DisAzo

5

50

Acid Black 2

Nigrosine Jet L

Azine

5

30

Acid Black 194

Black BR

MonoAzo

5

70

Acid Violet 17

Violet 4B

Triphenylmethane

1

40

Acid Violet 48

Violet BL

Anthraquinone

6

90

OrcoStain™ SS Solvent-Soluble Dyes

Shade

Index Name

OrcoStain™ SS

Specific Gravity g/cm3

Light Fastness (100 Hours – Xenon)

Solubility (Toluene)

Solvent Yellow 90

Yellow GL

1.560

7

50

Solvent Orange 99

Orange R

1.160

6

150

Solvent Orange 54

Orange RE

1.330

6

40

Solvent Red 119

Fire Red G

1.889

6

20

Solvent Red 89

Fire Red GLS

1.227

5

20

Solvent Red 160

Fire Red BL

1.250

5-6

500

Solvent Red 122

Red BL

1.330

6

150

Solvent Blue 70

Blue 2GN

1.235

5-6

40

Green BY-S

1.396

6

45

Solvent Brown 43

Brown 2RL

1.390

7

130

Solvent Black 29

Black RL

1.569

6

400

Solvent Black 27

Black RE

1.743

6

450

Actual pigment and dye samples must be evaluated in a laboratory on medium to be colored in production for accurate shade and physical property results. Shades shown on print material and computer monitors are for general reference only as they are inherently inaccurate due to calibration variations and technical limitations of monitors and printers.

KEY

BV=Bismuth Vanadate, Chromox=Chromium Oxide, CPX=Complex, ED=Easily Dispersible, IO=Iron Oxide, IR=InfraRed Reflective, Moly=Molybdate
