Gypsum & Wallboard of today are very technically advanced to address fire, mold & mildew, moisture, wind, sound, and durability construction codes and demands. Our dyes and pigments are chemically compatible with coating formulations necessary to meet these demands, when applied to wood, paper, or Fiberglas-mat facing.
Quick Links:
Inorganic Pigments(See Key) Orco BV™ | Orco Chrome™ | Orco CPX™ | Orco IO™ | Orco Moly™ | Orco UM™
Organic Pigments OrcoPerm™
Pigment Dispersions OrcoSperse™ Pigment Dispersions for Pulp & Paper
Dyes Acid Dyes for Pulp & Paper | Basic Dyes for Pulp & Paper | Direct Dyes for Pulp & Paper
Orco™ Inorganic Pigments
Shade
Index Name
Pigment Name
*= Workhorse colors
pH
Light Fastness (1-8)
Heat Stability (°F/°C)
Black 7
Orco Carbon Black JET™ *
6-8
8
1500 / 800
Black 28
Orco CPX™ Black ED-JT
4.8
8
1500 / 800
Blue 28
Orco CPX™ Blue BB *
9.5
8
1500 / 800
Blue 28
Orco CPX™ Blue ED-DB
5.1
8
1500 / 800
Blue 28
Orco CPX™ Blue TB
10.8
8
1500 / 800
Brown 29
Orco CPX™ Brown BBK
10.0
8
1500 / 800
Brown 33
Orco CPX™ Brown ED-RB
4.8
8
1500 / 800
Green 50
Orco CPX™ Green ED-RG
5.9
8
1500 / 800
Green 26
Orco CPX™ Green ED-DG
5.7
8
1500 / 800
Green 50
Orco CPX™ Green BG *
9.6
8
1500 / 800
Yellow 216
Orco CPX™ Orange C *
9.6
8
600 / 320
Yellow 216
Orco CPX™ Orange ED-MO
4.9
8
600 / 320
Violet 14
Orco CPX™ Violet BV *
7.8
8
1100 / 600
Yellow 53
Orco CPX™ Yellow BY
9.5
8
1500 / 800
Yellow 227
Orco CPX™ Yellow CHY
5.4
8
600 / 320
Yellow 53
Orco CPX™ Yellow ED-BY
4.5
8
1500 / 800
Yellow 227
Orco CPX™ Yellow ED-CHY
4.3
8
600 / 320
Brown 24
Orco CPX™ Yellow ED-GY
4.2
8
1500 / 800
–
Orco IO™ Gold Yellow S
4-7
–
–
–
Orco IO™ Gold Yellow S-M
4-7.5
–
–
Red 101
Orco IO™ Red S-M
4.5-7.5
–
930-1382 / 499-750
Black 11
Orco IO™ Black S-M
5-8
–
–
Black 26
Orco IO™ Black HT
7
8
1292/700
Shade
Index Name
OrcoPerm™
OR
*= Workhorse colors
pH
Light Fastness (1-8)
Heat Stability (°F/°C)
Yellow 3
Yellow GR
5-6.5
5-7
280 / 138
Yellow 13
Yellow GR-W
5-7.5
3-7
350-390 / 177-199
Yellow 14
Yellow 2GN *
5.0-7.5
3-5
390/199
Yellow 17
Yellow 3GN
5-7.5
4-7
390 / 199
Yellow 65
Yellow RNC
5.5-8
7-8
280/ 138
Yellow 73
Fast Yellow 4GX
6-7.5
5-7
280 / 138
Yellow 83
Golden Yellow RN *
5.5-7.5
7-8D
390 / 199
Yellow 97
Yellow FGL
6.5-8.5
5-8
350/ 177
Yellow 151
Yellow H4G *
5-7.5
6-8
390-500 / 199-260
Yellow 152
Yellow H2G
5.5-8
4-5
300 / 199
Yellow 154
Yellow H3G
5.5-7.5
8
320 / 160
Yellow 194
Yellow F2G
5.5-7.5
7-8
390/ 199
Orange 13
Fast Orange GR
5-6.5
3-6
350-390 / 177-199
Orange 36
Orange HL
9.5
7-8
320-500 / 160-260
Orange 67
Orange L
5.5-7.5
7
390 / 199
Red 5
Carmine FBX
5-7.5
5-6
1500 / 800
Red 48:2
Red 2BP *
6-7.5
4-7
375-460 / 190-238
Red 52:2
Maroon CM
5-7.5
3-5
460 / 238
–
Red 112
Red FGR
5.5-7
6-8
320-570 / 160-299
Red 122
Magenta LDN
6-8.5
6-8
320-570 / 160-299
Red 146
Carmine FBB
5-6.5
4-5D
350-390 / 177-199
Red 149
Fast Red B
6-7.5
6-8
430-560 / 221-293
Red 166
Scarlet R
6-7.5
7-8
390-570 / 199-299
Red 170
Fast Red FRK *
6-8
5-8
320-480 / 160-249
Red 177
Maroon PLG
5.5-7.5
7-8
390-500 / 199-260
Violet 23
Violet 4BN *
5-7
6-8
320-535 / 160-279
Blue 15:3
Blue 3GN *
5-8
8
302-554 / 150-290
Green 7
Green BN *
5.5-8
8
390-500 / 199-260
Green 7
Green YN *
5.5-8
8
350-500 / 177-260
Green 36
Cyanine Green 8G
5.5-8
8
390-500 / 199-260
Actual pigment and dye samples must be evaluated in a laboratory on medium to be colored in production for accurate shade and physical property results. Shades shown on print material and computer monitors are for general reference only as they are inherently inaccurate due to calibration variations and technical limitations of monitors and printers.
