Abrasives, Adhesives, Sealants, & Tape are miscellaneous construction materials requiring a broad array of dye and pigment classes to meet chemical compatibility and physical parameter requirements. Our colorants can be found in resin-bonded colored sanding discs, pads, belts, sponges, rolls, & sheets, wood and tile adhesives, highly durable and flexible silicon & butyl-based sealants, and tapes for industrial, insulation, & HVAC duct-work applications. Our standard line of dyes and pigments for abrasives, adhesives, sealants, & tapes are shown below. We have many other water-based dyes that can also be custom-formulated into your unique product application.



OrcoSolve™ Solvent Dyes

Solvent Dyes are used in many different applications in adhesive manufacturing, especially solvent-borne or hot melt adhesives. The coloring is used for branding and product aesthetics, but also for a visual inspection of adhesive application and coverage, especially for clear or partial opaque type adhesives.

Shade

Index Name

OrcoSolve™

Specific Gravity

(g/cm3)

Light Fastness (1-8)

Yellow 90

Yellow GL-MC

1.560

7

Yellow 82

Yellow 2GN-MC

1.211

6-7

Yellow 33

Chinoline Yellow

1.87

6

Orange 54

Orange RE-MC

1.330

6

Orange 99

Orange R-MC

1.160

6

Red 24

Red 4B

1.180

7-8

Red 111

Red SBA

1.400

6-7

Red 119

Fire Red G-MC

1.189

6

Red 122

Red B-MC

1.330

6

Blue 35

Blue B 200%

1.400

7

Blue 36

Blue AP

1.250

7

Blue 70

Blue 2GN-MC

1.235

5-6

Violet 13

Violet IRS

1.350

6

Green 3

Green B

1.350

6-7

Green –

Green BYS-MC

1.396

6

Brown 43

Brown 2RL-MC

1.390

7

Black 7

Nigrosine NB Base

1.250

5-6

Black 27

Black RE-MC

1.743

6

Actual pigment and dye samples must be evaluated in a laboratory on medium to be colored in production for accurate shade and physical property results. Shades shown on print material and computer monitors are for general reference only as they are inherently inaccurate due to calibration variations and technical limitations of monitors and printers.

OrcoSperseTM Pigment Dispersions

Pigment Dispersions are widely used in the water-based adhesive industry for product identification, product application indication, and for color compatibility with other finishes.

Pigment Dispersions also play a major part in the branding and consumer interest for adhesives tapes and sheet media. In these cases, the Pigment Dispersion is usually applied as a coating or surface layer.

Pigment Dispersions are widely used for branding, wear indications and product characteristics for many abrasive applications, such as sanding discs, pads, belts, and bristle type abrasives.

Shade

Pigment Index Name

OrcoSperse™

Light Fastness (Hours)

IIA Wash Fastness
Temperature Stability

             200 g/L

No CI

Fluorescent Blue G 2065

3-5

Pass

Heat Sensitive

No CI

Fluorescent Green B 4010

3-5

Pass

Heat Sensitive

No CI

Fluorescent Orange RN 9018

3-5

Pass

Heat Sensitive

No CI

Fluorescent Cerise 6200

3-5

Pass

Heat Sensitive

No CI

Fluorescent Pink BN 6027

3-5

Pass

Heat Sensitive

No CI

Fluorescent Red FP 6003

3-5

Pass

Heat Sensitive

No CI

Fluorescent Yellow GN 9026

3-5

Pass

Heat Sensitive

    100 g/L    10 g/L

Black 7

Black 2835

40-80

Pass

Stable to 375°F

Blue 15:1

Blue 2GN 2011

300

Pass

Stable to 375°F

Blue 15:1

Blue 2GN 2025

300

Pass

Stable to 375°F

Blue 15:3

Blue 3GN Conc

300

Pass

Stable to 375°F

Blue 29

Royal Blue RN 2008

60-100

Pass

Stable to 375°F

No CI

Brown RN 3000

100-150

Pass

Stable to 375°F

No CI

Brown 2KN 3012

40-80

Pass

Stable to 375°F

Green 7

Green BN 4009

300

Pass

Stable to 375°F

Green 7

Green YN 4020

300

Pass

Stable to 375°F

Orange 16

Orange 01/030

10-20

Pass

Stable to 375°F

Red 122

Magenta LDN 6141

100-140

Pass

Stable to 375°F

Red 23

Red 2RN 6110

20-60

Pass

Stable to 375°F

Red 31

Red Violet 3RN 6050

20-40

Pass

Stable to 375°F

Violet 19

Pink LBN 6032

100-120

Pass

Stable to 375°F

No CI

Red BRYN 6002

40-80

Pass

Stable to 375°F

No CI

Scarlet YDC 6019

40-80

Pass

Stable to 375°F

Red 123

Scarlet LDC 6034

100-120

Pass

Stable to 375°F

No CI

Red HS3B 6038

100-140

Pass

Stable to 375°F

Violet 23

Violet 4BN 7026

300

Pass

Stable to 375°F

Yellow 83

Golden Yellow RN 9018

80-100

Pass

Stable to 375°F

Yellow 14

Yellow 2GN 9000

20-40

Pass

Stable to 375°F

             160 g/L

No CI

White SGL 8002

500

Pass

Stable to 375°F

No CI

White R 8004

500

Pass

Stable to 375°F

No CI

Nonmetallic Silver 1012

Pass

Stable

Gold 1

Nonmetallic Gold 1012

Pass

Stable

Actual pigment samples must be evaluated in a laboratory on medium to be colored in production for accurate shade and physical property results. Shades shown on print material and computer monitors are for general reference only as they are inherently inaccurate due to calibration variations and technical limitations of monitors and printers.
